Agricultural Grain Planter 3 Rows Sowing Maize Planter Planting Equipment Agricultural Maize Seeder Machine In Africa

1 Set
MOQ
$1,350.00(>=1 Sets)
Precio
Agricultural Grain Planter 3 Rows Sowing Maize Planter Planting Equipment Agricultural Maize Seeder Machine In Africa
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Applicable Industries: Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Other
Number of Rows: 2, 3, 4, 5, 6
Showroom Location: None
Condition: New
Type: 3 point traction
Application: agricultural grain planter
Use: agricultural grain planter
Weight: 280 KG
Dimension(L*W*H): 1460**2400*1080mm
Warranty: 1 Year
Key Selling Points: Easy to Operate
Marketing Type: Ordinary Product
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Warranty of core components: 1 Year
Core Components: Other, Gear, Gearbox, Motor, Engine, Pump
Product name: planting agricultural equipment corn seeder machine in Africa
Color: Customer Request
customize: support customize
Matched power: 15-70Hp
Seeds: 2-6 rows
Seeding depth: 3-5cm
Plant spacing: 500-680 mm(can be adjusted)
Function: corn planting
Packing: Iron Cage/wooden
MOQ: 1 Set
Información básica
Pago y Envío Términos
Packaging Details: wooden packing,waterproof packing 3 rows seeding maize planter planting agricultural equipment corn seeder machine in Africa
Supply Ability: 120 Set/Sets per Month
Descripción de producto
Product Description
3 rows seeding maize planter planting agricultural equipment corn seeder machine in Africa
Model
2BYJ-2
2BYJ-3
2BYJ-4
2BYJ-5
2BYJ-6
rows
2
3
4
5
6
Matched power(hp)
11-22
11-22
30-48
30-50
50-70
Dimension(m)
1.6*1.26*1.08
1.6*1.66*108
1.6*2.4*1.08
1.8*2.8*1.15
1.8*3.44*1.18
Rows spacing(mm)
500-900
500-680
500-680
500-680
500-680
Working width(m)
1.16
1.56
2.3
2.7
3.3
Weight(kg)
178
240
300
370
480
Planting depth(cm)
3-6
3-6
3-6
3-6
3-6
Seeding crops
corn and soyabean
The planter consists of a machine frame, a fertilizer box, a device for discharging seeds, a device
for discharging fertilizer, a conduit for outputting seeds (fertilizer), a device for digging a trench, a device for covering soil, a walking wheel, a transmission device, a traction device, and a depth adjustment mechanism. The core of it is 1.Discharging seed implements; 2. Digging trenches.

1. Discharging seed implements

This corn planter is designed as an on- Point seeding-scoop wheel (teeth) planter.
The working process of the spoon wheel (tooth) type seed metering device: the seeds move upward under the action of the seed holding space, and 1~2 seeds are left in the spoon shape gear; the excess seeds fall back to the full seed area under the action of gravity. Advantages: 1.1 Can sow a variety of crops; 1.2 8-speed shift; 1.3 High precision seeding.

2.Digging trenches.

The mobile-shoe opener translates with the forward direction of the machine, and forms a certain angle
between the tip of the shovel and the ground to enter the soil, and adopts a solid cast steel shoe angle.
Advantages:
2.1 The alloy has high wear resistance and hardness;
2.2 It has strong ground-breaking ability;
2.3 The structure is simple and not easy to be damaged;
2.4 It has a compacting effect on the soil at the bottom of the trench, which promotes the rise of water in the soil, which is beneficial to the germination of seeds..

3. Fertilizer discharge device

This planter uses an external groove wheel type fertilizer discharger, which is suitable for
discharging granular fertilizer with good looseness.
Advantages: 3.1 The amount of fertilizer can be adjusted by adjusting the handle;
3.2 The fertilizer device is simple in structure and easy to replace;
3.3 The amount of fertilizer is uniform.

4.Squeeze

The flat sowing pressure of the repression wheel is 196-392KPa, and the ridge sowing pressure is
196-496KPa. This is made of high quality rubber thickened steel plate. The pressure can be adjusted by rotating the nut according to the soil sowing conditions. The pressure is generally required to be equivalent to the pressure of the human foot on the ground.

5. Cast steel profiling mechanism

When the ground rises and falls, the opener also rises and falls, so that the depth of the seed
relative to the ground surface is not affected by the unevenness of the ground. The advantage is that when the opener moves up and down, all parts of the entire seeding unit move up and down in parallel, without relative movement or rotation, and without changing the soil entry angle of the opener.
Project cases
Product packaging
Customized models

Customized models 1

6 rows without Fertilizer box

Customized models 2

4 rows peanut seeder and 4 rows corn seeder

Customized models 3

9 rows wheat seeder and 3 rows corn seeder
